Handheld 4.3 Inch TFT LCD CCTV Analog Security Camera Tester

56 reviews

Amazon

Brand: CamonityWeight: 0.56 kgSize: . PleaseW: 7.01 inchesH: 4.33 inchesD: 1.57 inches

Features

Portable Product--Portable product is able to use in any place and any time. It is easy to hold and do not need complicated equipment that hinders the inspecting and repairing
Monitor--4.3" high image resolution monitor enable to show clear image that fits any place to use
Long Work Time--Equips with Lithium battery of high capability. Each 6hours recharge durables 5 ~8 working hours
Humanized Design of Appearance--Hand-hold design for professionals. Easy operation without taking off gloves speeds your works. Clasp ring at bottom fits to all chains and use in all environments
Support DC Power for Camera--It's convenient for user to check camera condition and correct direction of camera, so to make installation and repairing easier

About this item

Specification: Display: 4.3" TFT Color LCD Number of Pixel: 480RGB(H) x 272(V) Video In: Video In x 1 (BNC connector) Export: 7 kinds of color bar signal output DC power out x 1 (Support CCD camera of power source/ Max electric currency 1500mA) System Format: AHD-CVBS-NTSC / PAL Battery Specification: Built-in rechargeable Lithium battery: 3.7V 3000mA/h Power Specification: External power: DC 5V 1.0A Adapter Dimension/ Weight: 178mm (L) x 110mm (W) x 40mm (H) / 350g Question: Can this unit work on digital IP cameras as well as analog?

This device is for viewing a standard analog camera.

You need a computer or tablet and a network to be able to view an IP Cam.

This device will not show a picture from the newer cvi cameras either.

A IP Cam outputs through a built in webserver which is why you need a computer and network.

Question: Why can'tturn on the device?

1.Check battery power capability.

2.Check if correctly using the original manufactured re-charger.

3.Check if the re-charger is normal function.

Question: Why can't the image function normally?

1.Check if the camera connects correctly with the terminal of the mainframe.

2.Check if the power is on or off.

3.Check power volume.
